Design a stackable box
Sharp open-top box with a raised collar on the rim. Identical boxes stack with the upper body sitting inside the lower collar — both flat bottoms preserved.
Stackable Box Specifications
Sharp edges
mm
mm
mm
mm
mm
Stacking rim
Outer walls stay perfectly vertical all the way up, so identical boxes sit edge-to-edge with no wasted space. Stacking uses a rabbet joint — the upper box's recessed bottom edge drops into the lower box's widened top opening with the requested clearance on each side, and rests on an internal shelf one rim-height below the top edge.
mm
How tall the wide upper section is. The internal shelf sits this far below the top edge.
mm
The most important value for fit. Typical FDM tolerance: 0.4 mm.
